DESCRIPTION- Smallest digital comparator available on the market with compact Ø 45 mm non-rotating housing and integrated Bluetooth® system
- New robust construction
- Ideal for integration into machines or various measuring fixtures
- Data output «Power», works without battery when connected via cable
- Three buttons, including the central button with selectable favourite function
- Wide range of functions, including MIN/MAX/DELTA
- Digital display resolution 0.01 or 0.001 mm with analogue scale
- Measuring range 12.5 mm
- Available in Protected or Standard execution
- P version: IP67 with bellows-protected spindle, without lifting cap
- S version: IP54 or IP67, without bellows, with or without lifting cap
FEATURES- Seamless Integration: Integrate our digital indicator effortlessly into machines or measuring fixtures, optimizing your workflow. With it compact Ø 45 mm non-rotating housing and robust design, it is the ideal solution for space-constrained environments.
- Wireles data acquisition: Our digital indicator is equipped with integrated Bluetooth® technology, allowing you to transmit measurements wirelessly, quickly and error-free for enhanced productivity.
- Efficiency Perfected: Achieve optimal efficiency with a central button for preset recall and value transmission. Experience error-free operation through hidden setup, preventing user mistakes. Enjoy extended battery life with automatic power shut down. Effortlessly select mm/inch and measurement direction for accurate results.
- Robust Executions: Tailor the execution of our digital comparator to meet your exact needs. Choose between the Protected (P) version, featuring IP67 protection with a bellows-protected spindle, or the Standard (S) version with IP54 protection and a lifting cap. Clamping stem Ø 8-h6 of hardened and ground stainless steel.
- High Precision and Versatility: Achieve high precision with the digital display resolution options of 0.01 or 0.001 mm. With a measuring range of 12.5 mm, this comparator caters to a wide range of measurement needs.
