SYLVAC - Digital Lever Probe LPD Smart

DESCRIPTION

• Lever probe with Bluetooth® technology integrated

• Unique on the market !

• Instrument for checking linear and circular geometry

• M2 stylus with Ø 3 mm tungsten carbide ball, swivelling and interchangeable

• Powered by CR2477 lithium battery

• Option to install a 32.3 mm long probe (optional)

• Compatible with our Sylcom and Vmux software and our D62S*, D300S and D400S* display units

• Exceptionnal Measurement Capabilities: Sylvac’s absolute lever probe delivers an impressive resolution of 0.01 µm for the most demanding measurement tasks. Engineered for reliability, it minimizes hysteresis to ensure consistent and accurate results with outstanding repeatability and accuracy.

• Direct Digital Output: The probe can be connected directly to a computer via Bluetooth® wireless technology, allowing for seamless integration with data acquisition software such as Sylcom without the need for additional modules or display units.

• Compact and Versatile Design: With a maximum thickness of 16 mm, it’s tailored for applications in tight spaces and offers a dovetail mounting system for maximum flexibility. Our lever probe can handle a variety of setups, from jigs and fixtures to
• integration with height gauges or PLCs.

• Key applications:
  • Integration into measuring jigs and fixtures
  • Integration into automation, interaction with PLC
  • Installation and maintenance of machines
  • Laboratory measurements, for example for flatness, runoutor perpendicularity
  • Workshop applications, measurements on the machine
  • Measurement with height gauge

• Use Cases: This lever probe is particularly effective for:
  • Measurements in restricted or enclosed spaces.
  • Assessing geometric tolerances (e.g., runout, concentricity).
  • Non-contact surfaces not measurable via optical systems.
  • Dynamic measurements.
• Exceptional Compatibility: Sylvac’s lever probes are fully compatible with the following Sylvac software and display units:
  • D300S
  • D400S*
  • D62S*
  • Sylcom: Version 1.3.1 and higher (USB).
  • Vmux: Version 1.35 and higher (USB).

* Soon available

SPECIFICATION
