Instrument for checking linear and circular geometry
M2 stylus with Ø 3 mm tungsten carbide ball, swivelling and interchangeable
Available in 3 versions :
Model with direct output USB
Model with direct output M8
Model with direct output OPEN
Option to install a 32.3 mm long probe (optional)
Compatible with our Sylcom and Vmux software and our D62S, D300S and D400S display units
FEATURES
Exceptionnal Measurement Capabilities: Sylvac’s absolute lever probe delivers an impressive resolution of 0.01 µm for the most demanding measurement tasks. Engineered for reliability, it minimizes hysteresis to ensure consistent and accurate results with outstanding repeatability and accuracy.
Direct Digital Output: The probe can be connected directly to a computer via USB or an M8 industrial connector, allowing for seamless integration with data acquisition software such as Sylcom without the need for additional modules or display units.
Compact and Versatile Design: With a maximum thickness of 16 mm, it’s tailored for applications in tight spaces and offers a dovetail mounting system for maximum flexibility. Our lever probe can handle a variety of setups, from jigs and fixtures to integration with height gauges or PLCs.
Key applications:
Integration into measuring jigs and fixtures
Integration into automation, interaction with PLC
Installation and maintenance of machines
Laboratory measurements, for example for flatness, runoutor
perpendicularity
Workshop applications, measurements on the machine
Measurement with height gauge
Use Cases: This lever probe is particularly effective for:
