Brand : SIUI (china made )
---------------------------------------

Bring More Possibilities for Your Inspection

SyncScan 3 is 64:128PR PAUT flaw detector with total focusing method (TFM) and 4-ch TOFD, which bring more possibilities for your inspection in oil & gas, transportation, aerospace, shipbuilding, manufacturing industries.

One-touch Smart Keys

Overviwe

• IP65
• 6 kg with batteries
• 365x270x115(mm)
• 12.1"touch screen, 1024x768 pixels

Unique Algorithm - Faster Live TFM

• SyncScan 3 adopts special algorithm (patent pending) to achieve live TFM high-speed imaging, basing on reducing data transmission and computing resources.
• The envelope processing provides more stable amplitude and removes noises, which further improves TFM performance.
  The shape and size of defects are characterized clearly.

64 PA, 4-ch TOFD - Higher Configuration for Demanding Inspections

• 64 PA channels can provide better coverage and accuracy, suitable for inspecting complex composite materials, corrosion-resistant alloys and austenitic materials, etc.
• SyncScan 3 is equipped with 4 TOFD channels. With special PA to TOFD adapter, its PA channel can convert to TOFD channel to achieve 5-ch TOFD inspection, suitable for thick weld up to 400mm, with low carbon steel/ alloy steel materials.

FMC -Supports Raw Data Analysis

Raw data can be recorded during full matrix capture (FMC) scanning, realizing data secondary development.

4 New Modules- Enhanced Wireless Transmission

• RF/ Bluetooth modules:
  Automatic crawler can be real-time controlled by SyncScan 3 directly without remote control.
  RF module supports transmission distance up to hundreds of meters.
• WIFI / 4G modules:
  WIFI assists data acquisition, ensuring real-time data transfer from equipment to PC, convenient and high efficiency.
  New SIM card connector can be inserted into the SIM card to turn on the 4G network, enabling wireless connection anytime and anywhere. GPS is also available.

Test Wizard -Retain Friendly and Upgradable

• SyncScan 3 continues to adopt step-by-step test wizard to guide users during the whole testing process, retains usual friendly experience.
• In TFM , the upgraded rectangle frame visualizes detection coverage, enables users to finish testing setup more quickly.

Technical Specification
