With this high-precision torque sensor, it is possible to carry out static and dynamic measurements in non-rotating applications. The sensor is particularly easy to integrate into existing or new screwdriving applications thanks to the internal and external square mechanical terminals.
Especially in the field of quality assurance and monitoring of screwdriving tools, the sensor can fully utilise its advantages such as built-in amplifier, support bearing for lateral force support and USB interface.
Non-rotating parts ensure maintenance-free operation when used properly.
Thanks to its modular design, the strain gauge-based sensor can be configured precisely for the desired area of application.
With the integrated amplifier option, the sensor directly supplies a voltage signal of 0 ... ±10 V. The sensor can be configured via the micro USB interface, e.g. setting a filter frequency, averaging and a tare function are available. With the USB measuring option, the measuring function via USB is also available in addition to the voltage output. Measurement and data storage can be carried out using the DigiVision software supplied; in addition, drivers are available for LabVIEW, for example. Integration into your own programmes using DLL is also possible.
With the burster TEDS option (electronic data sheet, memory chip with the sensor-specific sensitivities), quick configuration of compatible evaluation units (measuring amplifiers, indicators, etc.) is possible.
