Optical measurement SYLVAC SCAN S65

DESCRIPTION

• Vertical optical measuring machine for static and dynamic measurement of various elements on cylindrical parts up to Ø65mm

• The parts can be mounted between centres or held in place using various accessories

• Next generation machine incorporating the latest optical and imaging technology

• Rapid measurement with enhanced speed and accuracy

• 8” Touch screen panel for operator control directly on the shopfloor

• Dynamic LED lighting for measurement status

• Integrated calibration master with temperature sensors for environmental control

• Retractable roof for easy top loading of the heavy parts

• Optional tilt axis to facilitate measurement of threads such as, parallel, trapezoidal, conical, round, worms, ball screws, bone screws, etc.

• Reflex SCAN+ concept for measuring parts without prior programming at the touch of a button

• Delivered complete with a PC and the Reflex SCAN+ software

• The machine is delivered fully equipped «Automation Ready» as standard

• Motorized tailstock : essential for full automation integration
• Adjustable clamping force : adaptable to any type of part
• LED-illuminated interior : for improved setup visibility
• 8” touchscreen interface : simple, fast, and user-friendly operation
• Quick-release tooling (ISO) : for rapid part changeovers
