ERGOTEST DIGI – Digital Hardness Tester (DIGI 25 R)
Attribute:
"GALILEO" (Made in Italy) DIGI 25 R digital hardness tester for performs standard Rockwell tests
Categories : Inspection Product , Hardness Tester , Rockwell Hardness Tester , Clearance sales ,
Brand : GALILEO
Share
Digital hardness tester I DIGI 25 R
Ergotest DIGI: the state-of-the-art range of Galileo hardness testers. Recently renovated and updated with a more sophisticated software which controls all the instrument functions and the complete measuring process.
The operative interface is simplified thanks to the colour touch screen panel while the load selection is effected by means of a handy-placed knob on the right side of the machine.
The test is carried out automatically when a signal confirms that the pre-load has been applied correctly.
The software also allows to send data to the other peripherals either via USB port or configuring the LAN connection.
| Working principle | Rockwell |
For standard Rockwell tests | 150 kgf - 100 kgf - 60 kgf |
| For superficial Rockwell tests with loads | Not Applicabile |
| For Brinell indentations with loads* | 250 kgf - 187.5 kgf - 100 kgf - 62.5 kgf |
| For Vickers indentations with loads* | 100 kgf - 60 kgf |
| Standard |
| Standard |
| Automatic conversion of the values measured in the various hardness scales: Rockwell, Brinell, Knoop, Vickers as well as tensile strength according to either “Galileo conversion tables”, ISO 18265 or ASTM E140 standards | Standard |
| “Go-no go” function | Standard |
| Automatic test cycle with electronic process control | Standard |
| Load dwelling time 1-99 s selectable by keyboard | Standard |
| Maximum height of the workpiece | 295 mm |
| Throat depth | 220 mm |
| Automatic pre-load selection | 10 kgf |
| Self diagnosis program | Standard |
| USB port | Standard |
| LAN connection | Standard |
| Load selection by knob | Standard |
| Net Weight | 150 kg |
| Overall Dimensions (WxDxH) | 230 x 615 x 930 mm |
