K450T - External Caliper Gauge (Electronic) 0 - 50 mm
Attribute:
"KROEPLIN" (Made in Germany) Measurement of foamed material and foils I Range 0-50 mm. & Depth 167 mm. I Flat Ø 50 mm
Categories : Metrology Product , Caliper Gauge , External Caliper Gauge , Measurement of foamed material and foils ,
Brand : KROEPLIN
Share
K450T - External caliper gauge
Brand : KROEPLIN (Made in Germany)
-----------------
Electronic external measuring gauge
Measurement of foamed material and foils
- Measuring range Meb: 0 – 50 mm
- Numerical interval Zw: 0,02 / 0,05mm
- Measuring depth L max.: 167 mm
Additional information - caliper gauge
| Type | K450T |
| Display mm / inch | mm + inch |
| Application | Measurement of foamed material and foils |
| Measuring span Mes | 50 mm |
| Measuring range Meb | 0 – 50 mm |
| Range of indication Azb | 0 – 50,5 mm |
| Numerical interval Zw | 0,02 / 0,05 mm |
| Max. permissible errors G | 0,08 mm |
| Repeatability limit r | 0,06 mm |
| Measuring force F min. | 0,8 N |
| Measuring force F max. | 1.7 N |
| Type of measuring contact movable | Flat Ø 50 mm |
| Measuring contact movable Hb | 36 mm |
| Type of measuring contact fixed | Flat Ø 50 mm |
| Measuring contact fixed Hf | 24 mm |
| Measuring depth max. L | 167 mm |
| Weight | 500 g |
| Protection class | IP67 |
