C16200 - External Caliper Gauge (Electronic) 0-200 mm
Attribute:
"KROEPLIN" (Made in Germany) Measurement of grooves and thickness I Range 0-200 mm. & Depth 729 mm. Hemisphere SR 20 mm
Categories : Metrology Product , Caliper Gauge , External Caliper Gauge , Measurement of grooves and thickness ,
Brand : KROEPLIN
Share
C16200 - External caliper gauge
Brand : KROEPLIN (Made in Germany)
-----------------
Electronic external measuring gauge
Measurement of grooves and thickness
- Measuring range Meb: 0 – 200 mm
- Numerical interval Zw: 0,2 mm
- Measuring depth L max.: 729 mm
Additional information - caliper gauge
| Type | C16200 |
| Display mm / inch | mm + inch |
| Application | External measurement |
| Measuring span Mes | 200 mm |
| Measuring range Meb | 0 – 200 mm |
| Range of indication Azb | 0 – 201 mm |
| Numerical interval Zw | 0,2 mm |
| Max. permissible errors G | 0,4 mm |
| Repeatability limit r | 0,2 mm |
| Measuring force F min. | 0,8 N |
| Measuring force F max. | 5 N |
| Type of measuring contact movable | Hemisphere SR 20 mm |
| Measuring contact movable Hb | 98 mm |
| Type of measuring contact fixed | Hemisphere SR 20 mm |
| Measuring contact fixed Hf | 98 mm |
| Measuring depth max. L | 729 mm |
| Weight | 1300 g |
| Protection class | IP67 |
