Multiplexer unit D200S
Attribute:
Unit for connecting up to 8 SYLVAC capacitive probes and visualising the results on a PC (software included) or exporting the data.
Versions
Categories : Metrology Product , Probe, Digital Display & Modular , Digital Display ,
Brand : SYLVAC
Share
Multiplexer unit D200S
Brand: SYLVAC (swiss made)
--------------------------------------------
Description
- Unit for connecting up to 8 SYLVAC capacitive probes and visualising the results on a PC (software included) or
exporting the data. - Housing made of aluminium profile and ABS plastic that can be placed vertically or horizontally
- 8 inputs for capacitive sensors P5, P10 and P25
- I/O terminal block with opto-coupled inputs/outputs
- Free software to view up to 24 channels simultaneously, create channel combinations, perform dynamic measurements
or create sequences. - Up to 3 units can be connected to the software, so that up to 24 probe inputs can be used.
- Possibility to connect a D110V unit for lifting the vacuum probes
- 2 connectors for optional pedal 904-4101
- USB and RS232 data outputs
- IP50 protection
Digital display D62S
Brand: SYLVAC (swiss made)
----------------------
Technical Specifications
| 804-1200 | |
| Type | D200S |
| Max. Error | P2 : 1.5 / P5 : 1.6 / P10 : 1.6 / P25 : 1.9 µm |
| Repeatability | P2 : 0.2 / P5 : 0.2 / P10 : 0.2 / P25 : 0.2 µm |
| Frequency of measurement | 200 values /second |
| Overall dimensions | 304 x 171 x 61 mm |
| Weight | 1.2 kg |
| Case | Aluminium profile, Terlend plastic, ABS and aluminium vanished |
| Protection rating according to IEC 60529 | IP50 |
| Output data | USB / RS232 |
| Programmable by PC | • |
