D220T - External Caliper Gauge (Mechanical) 0-20 mm


"KROEPLIN" (Made in Germany) Measurement of foamed material and foils I Range 0-20 mm. & Depth 85 mm. I Flat Ø 10 mm



D220T - External caliper gauge

Brand : KROEPLIN (Made in Germany)


Mechanical external measuring gauge

Measurement of foamed material and foils

- Measuring range Meb: 0 – 20 mm

- Numerical interval Zw: 0,01 mm

- Measuring depth L max.: 85 mm


  Download Data sheet

  Download Catalog KROEPLIN


Additional information - caliper gauge

Display mm / inch
ApplicationMeasurement of foamed material and foils
Measuring span Mes20 mm
Measuring range Meb
0 – 20 mm
Range of indication Azb0 – 20,5 mm
Numerical interval Zw  0,01 mm
Max. permissible errors G0,04 mm
Repeatability limit r0,01 mm
Measuring force F min.1,1 N
Measuring force F max.
Type of measuring contact movableFlat Ø 10 mm
Measuring contact movable Hb28,2 mm
Type of measuring contact fixedFlat Ø 6 mm
Measuring contact fixed Hf20,7 mm
Measuring depth max. L85 mm
Weight220 g
Protection classIP67
