K2R20 - External Caliper Gauge (Electronic) 0-20 mm

Attribute:

"KROEPLIN" (Made in Germany) Measurement of foamed material and foils I Range 0-20 mm. & Depth 85 mm. HM-Ball Ø 1,5 mm

Brand : KROEPLIN

Share

K2R20 - External caliper gauge

Brand : KROEPLIN (Made in Germany)

-----------------

Mechanical external measuring gauge

Measurement of foamed material and foils

- Measuring range Meb: 0 – 20 mm

- Numerical interval Zw: 0,001 / 0,002 / 0,005 / 0,01 / 0,02 / 0,05mm

- Measuring depth L max.: 85 mm



  Download Data sheet

  Download Catalog KROEPLIN



Additional information - caliper gauge

Type
K2R20
Display mm / inch
inch, mm,  mm + inch
ApplicationMeasurement of tube wall thickness
Measuring span Mes20 mm
Measuring range Meb
0 – 20 mm
Range of indication Azb0 – 20,5 mm
Numerical interval Zw0,001 / 0,002 / 0,005 / 0,01 / 0,02 / 0,05mm
Max. permissible errors G0,03 mm
Repeatability limit r0,1 mm
Measuring force F min.1,1 N
Measuring force F max.1,6N
Type of measuring contact movableHM-Ball Ø 1,5 mm
Measuring contact movable Hb24,7 mm
Type of measuring contact fixedHM-Ball Ø 1,5 mm
Measuring contact fixed Hf2,5 mm
Measuring depth max. L80 mm
Weight290 g
Protection classIP67
